used injection moulding machine ENGEL Victory 500-120 Tech
| warehouse no.: | 502275 |
| manufacturer: | ENGEL |
| type: | Victory 500-120 Tech |
| controller: | CC 200 A01 |
| year of construction: | 2004 |
| operation hours: | 73541 h |
Our used injection molding machine is at our stock in Langenfeld (Rhineland) and would be technically tested before sale. The scope of delivery also includes the ENGEL ERC 33/1-FA robot. The control unit of the robot is integrated in the injection-molding-machine.
With this tested tieless injection molding machine, can technical plastic parts for the automotive industry or the electrical industry produced.
This ENGEL machine is available in spring 2017. If you have any questions, please do not hesitate to contact us.
This ENGEL machine is available from spring 2017. Please do not hesitate to contact us.
With this tested tieless injection molding machine, can technical plastic parts for the automotive industry or the electrical industry produced.
This ENGEL machine is available in spring 2017. If you have any questions, please do not hesitate to contact us.
This ENGEL machine is available from spring 2017. Please do not hesitate to contact us.
technical data clamping unit
| clamping force: | 1200 | kN |
| size of mould plates h x v: | 740 x 680 | mm |
| min. mould height: | 300 | mm |
| max. open daylight: | 800 | mm |
| opening stroke: | 506 | mm |
| ejector stroke: | 130 | mm |
| ejector force: | 40 | kN |
| centering diameter of moving platen: | 125 | mm |
| centering diameter of fixed platen: | 125 | mm |
| weight of mould: | 825 | kg |
technical data injection unit
| screw diameter: | 45 | mm |
| swept volume: | 318 | ccm |
| injection pressure: | 1028 | bar |
| screw speed: | 320 | min |
| injection rate into the open: | 250 | g/s PS |
| number of heating zones: | 5 | |
| nozzle stroke: | 300 | mm |
measures & weight
| measures of machine l x w x h: | 5.3m x 2.1m x 2.1m | |
| total weight: | 7400KG | |
equipment included
technical data robot-system
| handling type: | Linear Roboter-System | |
| manufacture: | ENGEL | |
| controller: | ERC 33/1-FA | |
| year of construction: | 2004 | |
| screen-text: | deutsch | |
| total weight: | 370 | kg |
